FTTH 1 GE 4 PORT EPON GPON ONU ONT WIFI CATV FIBER OPTIC NETWORK
ROUTER COMPATIBLE WITH OLT HUAWEI ZTE
Product Description:
BT-311XR Support GPON/EPON double mode self-suitable, with good
XPON inter -compatibility. Terminal supports powerful onlline
broadband business process ability, support L2/L3 multicast
forwarding, L2 bridge connection forwarding, L3router forwarding,
NAT/NAPT and etc business processing function;can achieve at
complicated protocol report processing and WIFI, USB and etc user
business processing. BT-PON ONU can support 1-2-way Voice
communciation. supporting G.711,G.722,G.729 as well as T.38 encode
and decode protocol, Supporting FAX/MODEM transsimition and echo
cancellation, voice activation test, comfortable background noise
production function and etc, supporting richful and flexible flow
seperation function; support HQoS achieve at layer design QoS.
Features:
- Support flexible QinQ VLAN,DHCP server/relay and IGMP/ MLD
multicast monitoring function;
- Support diagnostic monitoring and remote disabling of fiber
optical;
- Support 802.11n Wi-Fi(T/R)function;
- CATV function manageable,support CATV remote shutdown;
- Support NAT and firewall function;
- WAN support networking bridge, route and bridge/route mixed mode;
- Full speed 1G non-blocking switching
- 2048 MAC address table
- Support VLAN, transparent, tag, translation, trunk, etc.
- Integrated port monitoring, port mirroring, port rate limiting,
port SLA, etc
- Integrated IEEE802.1p QoS with four level priority queues
- Support IPv4/ IPv6 IGMP snooping and MLD snooping
- Support bridge, route and bridge/route mixed mode
Product Parameter:
| 1 GPON BOB (Class B+/Class C+) |
Receiving sensitivity: ≤-27dBm/≤-29dBm |
Transmitting optical power: +0.5~+5dBm/+2~+7dBm |
Transmission distance: 20KM |
| TX: 1310nm, RX: 1490nm |
| SC/APC Connector |
| 1 x 10/100/1000Mbps(GE) and 3 x 10/100Mbps(FE) auto adaptive
Ethernet interfaces. Full/Half, RJ45 connector |
| Compliant with IEEE802.11b/g/n, |
Operating frequency: 2.400-2.4835GHz |
support MIMO, rate up to 300Mbps, |
2T2R,2 external antenna 5dBi, |
Support: Multiple SSID |
Channel: Auto |
Modulation type: DSSS, CCK and OFDM |
Encoding scheme: BPSK, QPSK, 16QAM and 64QAM |
