SFP+ FTTH SFP Cassette GPON 16 Port OLT

Ask Lasest Price
Brand Name :	BT-PON
Model Number :	BT-P8116H
Certification :	CE
Supply Ability :	10000 Unit/Units per Month
Payment Terms :
Price :	Negotiation

Add to Cart

Product Details
Company Profile

SFP+ FTTH SFP Cassette GPON 16 Port OLT

BT-PON BT-P8116H 16 PON PORT FTTH SFP GPON OLT

Product Description

GPON OLT 16PON is a small-capacity cassette GPON OLT, meeting the
requirements of ITU-T G.984/G.988 and relative standards of China Telecom/Unicom GPON, with super GPON access capacity, carrier-class reliability and
the complete security function. It can satisfy long-distance
optical fiber access requirement on account of its excellent
management, maintenance and monitoring capability, abundant service
features and flexible network mode. GPON OLT 16PON can be used with
network management system so as to provide users with the
comprehensive access and perfect solution.
It provides 16 * downlink GPON port, 4 *GE combo port and 2* 10G
SFP+ port for uplink. The height is only 1U for easy installation
and space saving. GPON OLT 16PON is suitable for Broadcast three in one, video surveillance network, enterprise LAN, Internet of Things,
etc.
ItemGPON OLT 16PON
Service Port16*PON port, 4*GE COMBO port, 2*10GE SFP+ port
Redundancy DesignDual power supply
Support AC input, double DC input and AC+DC input
Power SupplyAC: input 90～264V　47/63Hz;
DC: input -36V～-72V;
Power Consumption≤110W
Dimensions (Width x Height x Depth)440mm×44mm×410mm
Weight (Full-Loaded)≤7.5kg
Environmental RequirementsWorking temperature: -10°C～55°C
Storage temperature: -40°C～70°C
Relative humidity: 10%～90%, non-condensing
ItemGPON OLT 16PON
PON Features

ITU-TG.984.x standard
Maximum 20 Km PON transmission distance
access 128 terminals for single fiber PON
Uplink and downlink triple churning encrypted function with 128Bits
ONU terminal legitimacy certification, report illegal ONU
registration
DBA algorithm, the particle is 1Kbit/s
Standard OMCI management function
ONU batch software upgrade, fixed time upgrade, real time upgrade
PON port optical power detection
L2 FeaturesMACMAC Black Hole
Port MAC Limit
64K MAC (packet exchange chip cache 2MB, external cache 720 MB )
VLAN4K VLAN entries
Port-based/MAC-based/protocol/IP subnet-based
QinQ and flexible QinQ (StackedVLAN)
VLAN Swap and VLAN Remark
PVLAN to realize port isolation and saving public-vlan resources
GVRP
Spanning TreeSTP/RSTP/MSTP
Remote loop detecting
PortBi-directional bandwidth
control
Static link aggregation and LACP(Link Aggregation Control Protocol)
Port mirroring
Security
Features
User’s SecurityAnti-ARP-spoofing
Anti-ARP-flooding
IP Source Guard create IP+VLAN+MAC+Port binding
Port Isolation
MAC address binding to the port and MAC address filtering
IEEE 802.1x and AAA/Radius authentication
Device SecurityAnti-DOS attack(such as ARP,
Synflood, Smurf, ICMP attack), ARP
detection, worm and Msblaster worm attack
SSHv2 Secure Shell
SNMP v3 encrypted management
Security IP login through Telnet
Hierarchical management and password protection of users
Network SecurityUser-based MAC and ARP traffic
examination
Restrict ARP traffic of each user and force-out user with abnormal
ARP traffic
Dynamic ARP table-based binding
IP+VLAN+MAC+Port binding
L2 to L7 ACL flow filtration mechanism on the 80 bytes of the head
of user-defined packet
Port-based broadcast/multicast suppression and auto-shutdown risk
port
URPF to prevent IP address counterfeit and attack
DHCP Option82 and PPPoE+ upload user’s physical location Plaintext
authentication of OSPF, RIPv2 and BGPv4 packets and MD5
cryptograph authentication
Service Features

ACLStandard and extended ACL
Time Range ACL
Flow classification and flow definition based on source/destination MAC address, VLAN, 802.1p, ToS, DiffServ, source/destination
IP(IPv4/IPv6) address, TCP/UDP port number, protocol type, etc
packet filtration of L2～L7 deep to 80 bytes of IP packet head
QoSRate-limit to packet
sending/receiving speed of port or self-defined flow and provide
general flow monitor and two-speed tri-color monitor of
self-defined flow
Priority remark to port or self-defined flow and provide 802.1P,
DSCP priority and Remark
CAR(Committed Access Rate), Traffic Shaping and flow statistics
Packet mirror and redirection of interface and self-defined flow
Super queue scheduler based on port or self-defined flow. Each
port/
flow supports 8 priority queues and scheduler of SP, WRR and
SP+WRR.
Congestion avoid mechanism, including Tail-Drop and WRED
IPv4ARP Proxy
DHCP Relay
DHCP Server
Static Routing
RIPv1/v2
OSPFv2
ECMP
PBR
MulticastIGMPv1/v2/v3
IGMPv1/v2/v3 Snooping
IGMP Filter
MVR and cross VLAN multicast copy
IGMP Fast leave
IGMP Proxy
PIM-SM/PIM-DM/PIM-SSM
MLDv2/MLDv2 Snooping
ReliabilityLoop ProtectionERRP or ERPS
Loopback-detection
Link ProtectionFlexLink (recover-time
<50ms)
RSTP/MSTP (recover-time <1s)
LACP (recover-time <10ms)
BFD
Device ProtectionVRRP host backup
1+1 power hot backup
MaintenanceNetwork MaintenancePort real-time, utilization
and transmit/receive statistic based on Telnet
RFC3176 sFlow analysis
LLDP
GPON OMCI
RFC 3164 BSD syslog Protocol
Ping and Traceroute
Device ManagementCLI, Console port, Telnet and
WEB
SNMPv1/v2/v3
RMON (Remote Monitoring)1,2,3,9 groups MIB
NTP
network management

Packing & Delivery

PACKING:
Original factory packing or customizedo,Or packed by standard
export carton.
Shipping way:
By air, by sea or express(UPS,DHL,Fedex,TNT,EMS...)We will make a
perfect delivery plan for you.
Delivery time:
1-7 days after order confirmed, exact delivery date should be
decided according to production season and order quantity.

Company Introduction

Shenzhen Baitong Putian Technology Co., Ltd is a professional
supplier focusing on R&D and sales, specializing in devices of
telecommunications of optical access network technology especially
ONU and OLT, ONU has EPON, GPON, XPON and Dual band with CATV. It
provides integrated network transmission products such as voice,
data, and video based on IP networks.We have provided advanced and cost-effective advanced services such
as product-oriented development and OEM & ODM for many industry
brands and large-scale projects at home and abroad. While creating
advanced and superior products for users, we have also created huge
brand values and markets for corporate customers. In addition, we
have applied the certificates of ISO9001 and CE in 2019.
The sales of products in the international market covers the rest
of the world and have been widely applied in the operator networks,
enterprise networks and industry projects in over 30 countries,
including South America, Africa, Eastern Europe, Southeast Asia,
and the Asia Pacific region.
