ANATEL 1 2 4 Core G657A FTTH Drop Cable

FIBER OPTIC CABLE 1 2 4 CORE G657A FTTH DROP CABLE WITH ANATEL

Product Description:

The structure of GYTS is to sheath 250um optical fiber into a loose tube made of high modulus material, and the loose tube is filled with waterproof compound. The center of the cable core is a metal reinforced core. For some fiber optic cables, a layer of polyethylene needs to be squeezed outside the metal reinforced core. The loose tube and the filling rope are twisted around the central reinforcing core to form a compact and circular cable core, and the gaps in the cable core are filled with water blocking fillers.

The optical fiber unit is positioned in the center. Two parallel reinforced steel wire are placed at the two sides. (A FRP as the additional strength member is also applied). then, the cable is completed with a black or color LSZH sheath.

Features:

Good mechanical and temperature performance
High strength loose tube that is hydrolysis resistant
Special tube filling compound ensure a critical protection of fiber
Crush resistance and flexibility
PSP enhancing moisture-proof
Two parallel steel wires ensure tensile strength
Small diameter, light weight and friendly installation
Storage / Operating Temperature: -40℃~+70℃

Product Parameter:

Cable Performance Parameter
Span meter	200	300	400
Related Strength Tension(RTS)	17.5 kn	20.6 kn	28 kn
Max Allowable Tension(MAT)	6.9 kn	8.2 kn	11.5 kn
Allowable Crush Resistance	Long Term: 1100 n/100mm	Long Term: 1100 n/100mm	Long Term: 1100 n/100mm
Allowable Crush Resistance	Short Term: 2200 n/100mm	Short Term: 2200 n/100mm	Short Term: 2200 n/100mm
Minimum Bending Radius	Operating: 220 mm	Operating: 220 mm	Operating: 220 mm
Minimum Bending Radius	Installlation: 360 mm	Installlation: 360 mm	Installlation: 360 mm
Temperature Range	Operating: -40 /+70℃	Operating: -40 /+70℃	Operating: -40 / +70℃
Temperature Range	Installlation: -15 / +60℃	Installlation: -15 / +60℃	Installlation: -15 / +60℃
Out Sheath Material	Electrical Resistance AT (Borealis material 6081) Sheath
Note	ice accretion 5MM,weed speed:30M/S

Fiber Parameter

No.	Items		Unit	Specification
No.	Items		Unit	G.652D
1	Mode Field Diameter	1310nm	μm	9.2±0.4
1	Mode Field Diameter	1550nm	μm	10.4±0.5
2	Cladding Diameter		μm	124.8±0.7
3	Cladding Non-Circularity		%	≤0.7
4	Core-Cladding Concentricity Error		μm	≤0.5
5	Coating Diameter		μm	245±5
6	Coating Non-Circularity		%	≤6.0
7	Cladding-Coating Concentricity Error		μm	≤12.0
8	Cable Cutoff Wavelength		nm	λcc≤1260
9	Attenuation (max.)	1310nm	dB/km	≤0.36
9	Attenuation (max.)	1550nm	dB/km	≤0.24
