10/100M SINGLE MODE OPTIC MEDIA CONVERTER SC WITH 1 RJ45 PORTS/2
PORTS FIBER OPTIC MEDIA CONVERTER 1LAN 1 FIBER
Product Description:
10/100/1000M adaptive fast Ethernet optical Sfp Media Converter is
a new product used for optical transmission via high-speed
Ethernet. It is capable of switching between twisted pair and
optical and relaying across 10/100/1000Base-TX to 1000Base-FX
network segments, meeting long-distance, high-speed and
high-broadband fast Ethernet workgroup users’ needs, achieving
high-speed remote interconnection for up to 100 km's relay-free
computer data network. With steady and reliable performance, design
in accordance with Ethernet standard , it is particularly
applicable to a wide range of fields requiring a variety of
broadband data network and high-reliability data transmission or
dedicated IP data transfer network.
The media converter transform the transmission media of Ethernet
signal from CAT5 to optical fiber. it can extend the transmission
distance to several kilometer or hundred kilometer.Using media
converter is a economical solution to achieve long distance
transmission base on current status.
Features:
- For intranet prepared for expansion from 100M to 1000M
- For integrated data network for multimedia such as image, voice and
etc.
- For point-to-point computer data transmission
- For computer data transmission network in a wide range of business
application
- For broadband campus network, cable TV and intelligent FTTB/FTTH
data tape
- In combination with switchboard or other computer network
facilitates for: chain-type, star-type and ring-type network and
other computer networks
Product Parameter:
| 0/100/1000M Dual fiber |
| Connector type | SC | SC | SC | SC | SC |
| Fiber type | Multi-mode | Single-mode | Single-mode | Single-mode | Single-mode |
| Wavelength | 850nm | 1310nm | 1310nm | 1550nm | 1550nm |
| Max Distance | 62.5µm: 224m | 20Km | 40Km | 60Km | 80Km |
| 50µm: 550m |
| Min TX PWR | -11.0dBm | -9.0dBm | -4.0dBm | -8.0dBm | -3.0dBm |
| Max TX PWR | -6.0dBm | -5.0dBm | 0dBm | 0dBm | 0dBm |
| Sensitivity | < -18dBm | < -21dBm | < -24dBm | < -25dBm | < -25dBm |
| Link Budget | 7.0dBm | 12.0dBm | 20.0dBm | 17.0dBm | 22.0dBm |
FAQ:
1.Can I get a sample free?
Yes,you need place sample order to us, and we will reduce from next
order .
2.How do I know your products are original and brand new ?
We guarantee products from our company are original and brand new.
We are the key distributor of Huawei,ZTE,Fiberhome, who get special
offer and technical support from them. Each model has S/N number
and we will send you the S/N list to you after shipping .You can
confirm with manufactures.
You will get competitive price and professional technical supports.
3.Could you do design for us?
Yes, we can do artwork including printing, logo etc. for you, if
you provide us the content and tell us where to put.
4.How can we place order?
Comfirm PI — Got the deposit — Arrange production/delivery
After we made agreement on the product's parameters, we will make
proforma invoice for your confirmation. When we got your advance
payment (deposit) we will arrange the production and delivery.
If you have your own ship forwarder, we will use your ship
forwarder to delivery goods. if not, then when the goods arrived at
Destination port, you must find a ship forwarder help you clear the
custom.
5.How about the shipping?
For small orders, we will send the goods by International Express
like HK Fedex, DHL, TNT or UPS. Usually it takes about 7 workdays
to arrive.If big quantity we will ship by Ocean transportation, it
takes one month to arrive. if urgnet, you can select shipping by
Air, but freight charge will be more expensive.
6.What's your products' advantages ?
A. Good quality and competetive prices.
B. Strictly quality control when producing.
C. Professional team work, from design, development, producing,
assemble, packing and shipping.
D. Good after-sale service. Professional online technical support
can be provided. Moreover, if any problem of the goods, we will
help to solve the problem or provide replacement of the goods.
